55" UHD 4K monitor with HDR emulation, 700 nits brightness, 12G-SDI and HDMI 2.0 support ideal for professional broadcast and post-production setups.
The TVLogic LUM-550M3 is a 55-inch True UHD 4K LCD monitor engineered for high-end broadcast, post-production, and control room environments where precision and performance are paramount. With a native resolution of 3840x2160 on a 10-bit panel and a peak brightness of 700cd/m², it delivers stunning clarity and color accuracy. The monitor supports a wide range of professional inputs including dual 12G/6G/3G/HD-SDI, quad 3G-SDI, and HDMI 2.0, offering maximum flexibility for modern 4K workflows. Its HDR emulation capabilities—supporting PQ, HLG, and SLog3—enable accurate monitoring of high dynamic range content. With 86% DCI-P3 color coverage and a sleek ultra-slim bezel design, the LUM-550M3 combines technical excellence with aesthetic appeal, making it an ideal choice for wall-mounted reference display applications in demanding visual environments.
Size 54.6"
Resolution 3840×2160(16:9)
Pixel Pitch 0.315(H) x 0.315(V) mm
Color Depth 1.07B Colors
Viewing Angle 178°(H) / 178°(V)
Luminance of white 700nits
Contrast Ratio 1100:1
Display Area 1209.6(H) x 680.4(V) mm
Audio In SDI Embedded Audio (Group, Channel Selectable)
Audio Out Analog Stereo (3.5mm Phone Jack)
Power AC100~240V(50~60Hz)
Power Consumption 150 Watts (Max.)
Input
1 x HDMI HDMI(2.0) Input
4 x BNC 12G/6G/3G/HD/SD-SDI Ch1/Ch2, 3G/HD/SD-SDI Ch3/Ch4
Output
4 x BNC 12G/3G/HD/SD-SDI Output 1Ch
By Pass Mode : SDI A/B Channel (Active Through Out)
12G Mode : 3840x2160 60p/59.94p/50p
Input Signal
12G-SDI 12Gb/s
6G-SDI 6Gb/s
3G-SDI 2.970Gb/s
HD-SDI 1.485Gb/s
HDMI 720p/1080p/2160p
AC Power Cable, IR Remote, Table Stand
