The Sony ILME-FX5 is a next-generation Cinema Line camera engineered for filmmakers who demand uncompromising image quality, advanced workflow flexibility, and professional operability in a highly compact form factor. Built around a newly developed full-frame, fully stacked Exmor RS™ CMOS sensor and powered by the latest BIONZ XR2™ processing engine with dedicated AI support, the FX5 delivers exceptional performance for cinematic productions, live events, documentaries, commercials, and high-end content creation.
Designed to bridge the gap between portability and production-grade capability, the FX5 captures stunning images with more than 15 stops of dynamic range when shooting in S-Log3, providing remarkable highlight retention, natural shadow reproduction, and extensive grading latitude in post-production. Three native base ISO settings of 800, 4000, and 12800 allow creators to maintain clean, low-noise images across a wide variety of lighting conditions, from controlled studio environments to demanding low-light productions.
For the first time in Sony’s FX Cinema Line series, the FX5 introduces Full-Frame Open Gate recording, offering maximum sensor utilization and unprecedented flexibility for reframing, anamorphic workflows, and multi-format delivery. Internal recording supports Sony’s professional 16-bit scene-linear X-OCN RAW format, eliminating the need for external RAW recorders while delivering exceptional color depth and image fidelity. The camera can record up to 5K Open Gate, 4K at up to 120 frames per second, and Full HD at up to 240 frames per second, enabling everything from cinematic slow motion to high-end visual effects workflows.
The integrated AI processing unit enhances production efficiency through advanced subject recognition and intelligent shooting assistance. Fast Hybrid Autofocus with up to 759 phase-detection points provides highly accurate tracking of humans, animals, and birds, while features such as Focus Map, AF Assist, adjustable transition speeds, and subject shift sensitivity give operators precise creative control over focus behavior.
Built specifically for professional productions, the FX5 combines robust connectivity with advanced workflow integration. Dual CFexpress Type A and SD card slots support high-speed recording, while 2.5GbE Ethernet, Wi-Fi 6E, Bluetooth 5.3, FTP transfer functionality, HDMI output, USB-C power delivery, and built-in streaming support for RTMP, RTMPS, and SRT enable seamless integration into modern production environments.
The camera features effective 5-axis image stabilization, a bright multi-angle 3.5-inch LCD monitor, professional audio capabilities, and compatibility with Sony’s optional XLR Handle Unit, which supports high-quality 32-bit float audio recording up to 96 kHz. Combined with its lightweight design and refined ergonomics, the FX5 is equally at home on a gimbal, shoulder rig, drone, or traditional cinema setup.
Created to meet the demands of modern filmmakers, the Sony FX5 delivers the cinematic look, advanced recording formats, AI-powered intelligence, and workflow versatility required for today's professional productions. Whether shooting feature films, documentaries, broadcast content, corporate productions, or live events, the FX5 provides a powerful platform for creators who demand maximum quality without compromise.
| Lens Mount |
Sony E-Mount |
| Image Sensor |
35.9 x 24.0 mm Full-Frame Exmor RS™ Stacked CMOS Sensor |
| Effective Resolution |
Approx. 18.2 MP |
| Image Processor |
BIONZ XR2™ with Dedicated AI Processing Unit |
| Dynamic Range |
15+ Stops (S-Log3) |
| Base ISO |
ISO 800 / 4000 / 12800 |
| ISO Range |
ISO 320 – 409600 |
| Recording Formats |
X-OCN, XAVC HS (H.265), XAVC S (H.264) |
| RAW Recording |
Internal 16-bit X-OCN |
| Open Gate Recording |
Yes (3:2 Full-Frame) |
| Maximum Recording Resolution |
5K Open Gate |
| Maximum 4K Frame Rate |
Up to 120 fps |
| Maximum HD Frame Rate |
Up to 240 fps |
| Colour Profiles |
S-Cinetone™, S-Log3 |
| Autofocus System |
Fast Hybrid AF |
| AF Points |
Up to 759 Phase Detection Points |
| Subject Recognition |
Human, Animal, Bird |
| Image Stabilisation |
5-Axis In-Body Stabilisation |
| Active Stabilisation |
Dynamic Active Mode |
| Display Size |
3.5" LCD Touchscreen |
| Display Resolution |
2.76 Million Dots |
| Memory Card Slots |
Dual Slots |
| Supported Media |
CFexpress Type A / SDXC UHS-I & UHS-II |
| HDMI Output |
Full-Size HDMI Type A |
| Ethernet |
2.5GBASE-T |
| Wireless LAN |
Wi-Fi 6E (2.4 / 5 / 6 GHz) |
| Bluetooth |
Version 5.3 |
| USB |
USB-C with Power Delivery |
| FTP Transfer |
LAN, Wi-Fi, USB Tethering |
| Streaming Protocols |
RTMP, RTMPS, SRT |
| Audio Recording |
Up to 4 Channels |
| Optional Audio Unit |
XLR Handle Unit |
| Audio Resolution |
Up to 32-bit Float / 96 kHz |
| Battery Type |
Sony NP-SA100 |
| Weight |
Approx. 734 g |
| Dimensions |
Approx. 132.2 × 79.0 × 87.0 mm |
