Blackmagic Mini Converter Audio to SDI 4K

BlackMagic Design

CONVMCAUDS4K

Blackmagic Mini Converter Audio to SDI 4K

High‑quality 4‑channel analog and 8‑channel AES audio embedding into any SD, HD or Ultra HD 6G‑SDI signal, ready for modern 4K broadcast workflows.

1-3 werkdagen

€269,10 (excl. btw)
€325,61 incl. btw
€299,00
- 0%

Aantal

This professional audio embedder is built to insert high‑fidelity analog or digital audio into SD, HD and Ultra HD 6G‑SDI video signals, making it an essential tool for complex modern broadcast environments. Designed for studios, mobile production units and post‑production facilities, it supports SDI video formats up to 1080p60 in HD and up to 2160p30 through its 6G‑SDI architecture. This ensures compatibility with both traditional HD workflows and emerging Ultra HD systems, while maintaining outstanding reliability and signal integrity. The device’s automatic SD, HD and 3G‑SDI detection streamlines daily operation by removing the need for manual configuration when switching between different video standards.

The unit embeds up to four channels of balanced analog audio or eight channels of AES/EBU digital audio directly into the SDI stream. This makes it ideal for integrating audio from professional mixers, analog sources or digital audio systems into routing networks, recorders and switchers. Thanks to 48 kHz and 24‑bit sampling, audio is preserved with broadcast‑grade clarity. The embedder also features a redundant SDI input that automatically takes over if the primary feed is lost, ensuring uninterrupted operation during live production or critical recording tasks. Its compliance with SMPTE standards including SMPTE 259M, 292M, 296M, 372M and 424M level B guarantees broad interoperability across industry‑standard infrastructure.

To accommodate 4K workflows, this model offers 6G‑SDI bandwidth, enabling precise embedding into Ultra HD video signals. Full support for 2K DCI formats ensures cinema‑grade compatibility, making the unit versatile across both broadcast and digital film environments. Its internal SDI reclocking stabilises long cable runs by minimizing jitter, preserving image and audio synchronisation even in complex routing systems. Configuration is managed via USB, allowing quick setup and firmware updates through the provided utility software.

Built in a compact, rugged metal housing, the converter withstands the demands of continuous professional use. A universal 12 V power supply with international adapters is included, making it suitable for installations worldwide. With reliable audio embedding, broad SDI compatibility and support for Ultra HD, the device is a powerful tool for bridging analog or AES audio equipment with 4K‑ready SDI systems in any professional environment.

Connections

SDI Video Inputs

1 x SD, HD or 6G‑SDI. 1 x ALT SDI Input for automatic switch over if main input fails.

SDI Video Outputs

1 x Embedded SDI Output.

Analog Audio Inputs

4 channels of professional balanced analog audio with standard 1/4 inch jack connections.

Digital Audio Inputs

8 channels of professional balanced digital with standard 1/4 inch jack connections.

SDI Redundant Input

Automatically switches over if main SDI input is lost.

Multi Rate Support

Auto detection SD, HD or 6G‑SDI.

Updates and Configuration

Via USB 2.0 high speed. (480 Mb/s)

Reclocking

Yes

Standards

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60

2K Video Standards

2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI, 2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30

4K Video Standards

4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI

SDI Compliance

SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE ST‑2081, ITU‑R BT.656 and ITU‑R BT.601

SDI Video Rates

SDI video inputs are automatically detected between standard definition and high definition.

SDI Video Sampling

4:2:2, 4:4:4

SDI Audio Sampling

Television standard sample rate of 48kHz and 24‑bit.

SDI Color Precision

4:2:2, 4:4:4

SDI Color Space

YUV, RGB

SDI Auto Switching

Automatically selects between SD, HD, 3G and 6G‑SDI.

Software

Software Control

Mac™ and Windows™ software upgrade via USB.

Internal Software Upgrade

Via included updater application.

Operating Systems

Mac 10.15 Catalina,
Mac 11.1 Big Sur or later.

Windows 10, 64-bit.

Settings Control

Mini Switches or USB software.

Power Requirements

Power Supply

+12V universal power supply included with international socket adapters for most countries. Cable tie point.

Power Consumption

8.40 Watts

Operational Voltage Range

12 ‑ 31V DC

Physical Specifications

Environmental Specifications

Operating temperature

0° to 40° C (32° to 104° F)

Storage temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing

What's Included

Mini Converter Audio to SDI 4K

12V universal power supply with international socket adapters

Warranty

3 Year Limited Manufacturer’s Warranty.

Mini Converter Audio to SDI 4K
12V universal power supply with international socket adapters
