BlackMagic Design
CONVNVIPF/IP/12G

Blackmagic 2110 IP Mini BiDirect 12G

A pocket‑sized bi‑directional gateway that links 12G‑SDI cameras to SMPTE‑2110 systems with full program return, talkback and uncompromised image quality.

Op voorraad
  • €283,50 (excl. btw)
    €343,04 incl. btw
  • €315,00
  • - 0%
This compact bi‑directional interface is designed to connect broadcast cameras directly to SMPTE‑2110 IP infrastructures while keeping the camera workflow simple and familiar. It handles both the outgoing camera signal and the incoming program return through a single device, making it ideal for live production environments where minimal cabling and fast setup are essential. Its small, in‑line form factor allows it to be mounted close to the camera or even used handheld, without adding unnecessary weight or complexity.
The unit supports a full‑bandwidth 12G‑SDI connection, automatically adapting to SD, HD, Ultra HD and DCI 4K formats up to 2160p60. This ensures compatibility with modern broadcast cameras as well as legacy systems, while providing a smooth upgrade path to IP‑based production. Both the camera feed and the SDI program return are converted to and from uncompressed IP video, maintaining image quality and timing accuracy throughout the signal chain.
Connectivity to the IP network is achieved via a single 10G Ethernet interface, allowing direct integration into managed SMPTE‑2110 systems. The device fully supports the SMPTE ST2110‑20, ‑21, ‑30 and ‑40 standards, ensuring proper handling of uncompressed video, audio and ancillary data. Precision Time Protocol support enables accurate synchronization with the rest of the network, which is critical for multi‑camera live production.
To support professional broadcast communication, a built‑in 5‑pin XLR headset connection is provided for talkback. Dedicated controls for volume and push‑to‑talk allow camera operators to stay in constant contact with the production team without additional intercom hardware. Embedded audio is carried transparently in both the SDI and IP streams, preserving all 16 audio channels and associated metadata.
Powering is flexible to suit different deployment scenarios. The unit can be powered directly over the 10G Ethernet connection using PoE, reducing cabling around the camera position, or via the included 12 V DC power supply with locking connector for standalone operation. Configuration and firmware updates are handled through USB‑C, simplifying maintenance and system updates in the field.

Connections

SDI Video Inputs

1

SDI Video Outputs

1

SDI Rates

1.5G, 3G, 6G, 12G.



SMPTE ST-2110 IP Video Inputs/Outputs

1 x 10G Ethernet

Analog Audio Inputs

1 x 5 pin XLR Talkback.

Analog Audio Outputs

1 x 5 pin XLR Talkback.

SDI Audio Inputs

16 Ch embedded audio on SDI input.

SDI Audio Outputs

16 Ch embedded audio on SDI output.

SMPTE ST 2110 IP Audio Inputs

16 Ch embedded audio on ST-2110 IP video via 10G Ethernet.

SMPTE ST 2110 IP Audio Outputs

16 Ch embedded audio on ST-2110 IP video via 10G Ethernet.

Multi Rate Support

Auto detection of HD, Ultra HD and 4K.

Reclocking

Yes

Ethernet

1 x 10Gb/s RJ‑45 connector for SMPTE‑2110 IP video in and out.

Computer Interface

1 x USB‑C for configuration and firmware updates.

Blackmagic 2110 IP Mini BiDirect 12G

SDI Video Standards

HD Video Standards

720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60
1080PsF25, 1080PsF29.97, 1080PsF30

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60

4K Video Standards

4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI.

SDI Compliance

SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M, SMPTE 2081‑1, SMPTE 2081‑10, SMPTE 2082‑1, SMPTE 2082‑10, SMPTE ST2110‑20, SMPTE ST2110‑21, SMPTE ST2110‑30, SMPTE ST2110‑40.

SDI Video Rates

SDI video connections are switchable between standard definition, 720p, 1080i, 1080p, 2K DCI, Ultra HD and 4K DCI.

SDI Color Precision

4:2:2

SDI Color Space

YUV

SDI Auto Switching

SDI video connections are switchable between 720p, 1080i, 1080p, Ultra HD and 4K DCI.

IP Video Compliance

SMPTE 2110-20 (Uncompressed Video)

IGMP v2

SMPTE 2110-21 (Traffic Shaping)

Sender: Narrow

Receiver: Narrow, Wide Synchronous, Asynchronous

SMPTE 2110-30 (PCM)

Audio Conformance level: Level C

SMPTE 2110-40 (Ancillary Data)

Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M-2, closed captioning and HDR static metadata.

Codec

Blackmagic IP10 codec used when converting 12G-SDI rates to 10G 2110 IP video.

Precision Time Protocol

IEEE 1588-2008 (PTP v2)

ST 2059-1

ST 2059-2

NMOS IS-04 Discovery and Registration

v1.3.2

Peer-to-peer via mDNS/DNS‑SD

NMOS IS-05 Connection Management

v1.1.2

NMOS BCP-002-01

Natural Grouping

NMOS BCP-004-01

Receiver capabilities

LED Indicators

1 x IP Input Lock LED indicator light

1 x SDI Input Lock LED indicator light

1 x Tally LED indicator light

Control

Talkback button controls for Volume Up, Volume Down and Push to Talk.

Talkback and Tally

Talkback

5‑pin XLR talkback headset connection for talkback on channels 15/16 in the SDI and 2110 IP video.

Live Tally Indicator

Tally LED indicator light

Operating Systems

Mac icon

Mac 13.0 Ventura,
Mac 14.0 Sonoma or later.

Windows Icon

Windows 10 and 11.

Power Requirements

Power Supply

1 x +12V DC external universal power supply with locking 5.5mm barrel Jack plus international socket adapters for most countries.

1 x RJ45 Ethernet connector for power from PoE++ power supplies.

Operational Voltage Range

12 - 16 V

Power Usage

18W

Physical Specifications

Blackmagic 2110 IP Mini BiDirect 12G

Environmental Specifications

Operating Temperature

5° to 40° C (41° to 104° F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing

What's Included

Blackmagic 2110 IP Mini BiDirect 12G

Plug Pack Power Supply with universal adaptor plugs

Warranty

1 Year Limited Manufacturer’s Warranty.

Blackmagic 2110 IP Mini BiDirect 12G

Plug Pack Power Supply with universal adaptor plugs
