Datavideo
2600-0219

Datavideo HDR-2 Recorder

4K H.265 recorder Supports up to UHD 4K (3840 x 2160) HDMI 2.0 input, output and loop-thru output, 2” LCD for setting and monitoring. Record on SD card, Balance XLR in x2 + RCA in x 2, Support DVIP and RS-232 control, GPI input

1-3 werkdagen
  • €1.325,00 (excl. btw)
    €1.603,25 incl. btw
  • - 0%
▼
  • Default Title

Capture, Create, and Elevate with HDR-2: Your Ultimate 4K Recording Solution

HDR-2 is a 4K50/60P SD card recorder with H.265/ H.264 encoding capabilities, allowing users to set different video formats and bitrates according to various application scenarios.

It enables the recording and playback of 4K videos without a computer, making it convenient for using as a recording device in on a live production site.

UHD 4K Resolution (3840 x 2160)

Immerse your audience in breathtaking clarity with HDR-2's support for ultra-high-definition 4K resolution, ensuring every detail is captured with stunning realism and precision.

HDMI 2.0 Connectivity

Seamlessly integrate your equipment with HDR-2's HDMI 2.0 input, output, and loop-through features, ensuring compatibility with a wide range of devices for fluid video transfer and monitoring.

2" LCD Monitor

Stay in control of your production with the built-in 2" LCD screen, offering real-time visual feedback and vital information at your fingertips, enhancing your recording precision.

Advanced Encoding Capabilities (H.265/H.264)

Elevate your video quality and efficiency with H.265 and H.264 encoding, enabling you to capture stunning visuals while optimizing storage space for extended recording sessions.

Convenient SD Card Recording

Free yourself from the constraints of a computer setup with the HDR-2's autonomous SD card recording, allowing you to effortlessly capture 4K content on the go, whether on location or during live events.

Video Standard

4K & HD

Video Format

3840x2160p: 60/59.94/50 (H.265 Only)
3840x2160p: 30/29.97/25/24/23.98
1080p: 60/59.94/50/30/29.97/25/24/23.98
720p: 60/59.94/50

Supported Video Input Signal

1 x HDMI 2.0 Type A

Video Output

2 x HDMI 2.0 Type A
1 x HDMI 2.0 Type A Loop out

Analog Audio Input

2 x 3 Pin XLR Socket
1 x Stereo RCA set (L/R)

Analog Audio Output

3.5mm earphone jack

Embedded Audio

De-embedded Digital Audio (2 CH) Input
Embedded Digital Audio (2 CH) Output

Storage Medium

SD Card Slot x 1
Supports SD, SDHC and SDXC card (UHS-I) (U3 above)
Max.: 128GB

Multi-channel Recording

1-CH HDMI 4K & HD

Estimated Record Time (min per 10GB)

HD 32GB: 56Hr (1Mbps)~ 7Hr (8Mbps)
FHD 32GB: 28Hr (2Mbps)~ 3.5Hr (16Mbps)
UHD 32GB: 7Hr (8Mbps)~ 1.7Hr (32Mbps)

Recording Media

1 x SD Card

Storage File System

exFAT

Recorded File Format

MP4(H.265+ AAC) or (H.264+ AAC)

Video Recording Bit Rate / Color Sampling

YUV 4:2:0 / 8bit
bitrate:1Mbps~50Mbps

Audio Recording Format

AAC 2CH,
16bit 48KHz 192Kbps

Encode Supported

H.264: MAX RES: 4K@30 420 8bit codec
H.265: MAX RES: 4K@60 420 8bit codec

Video Bitrate

H.265: 50Mbps / H.264: 50Mbps

Preview Display

2” LCD (MENU)

Time Code In / Out

----

External Sync / Genlock

----

External Control

DVIP, RS-422/ RS-232
GPI Input: 3.5Ø phone jack (Pulse trigger: Record Start/Stop)
Front Key Buttons

Power Failure Protection

Redundant USB power supply (not included)

Chassis

1RU, Half-rack Width

Dimension (LxWxH)

220 x 237 x 47 mm

Weight

1.4 kg

Operating Temp. Range

0~40 °C

Power

DC 12V, 2A

1 x HDR-2 product
1 x AD Switch DC 12V
