A fully integrated Ultra HD broadcast studio combining powerful switching, internal recording, advanced keying and high‑speed 10G networking in a compact all‑in‑one design.
8
12
1.5G, 3G, 6G, 12G
1
2 x XLR balanced analog audio,
1 x BNC 32 Ch MADI digital audio,
2 x RCA stereo analog audio,
1 x 5 pin XLR Talkback.
4 x 1/4 inch Jack analog audio,
1 x BNC 64 Ch MADI digital audio, up to 50 active,
1 x 5 pin XLR Talkback.
4 Ch embedded audio on all SDI inputs.
16 assignable channels.
1 x BNC In, 1 x BNC Out.
1 x BNC In, 1 x BNC Out.
Tri-Sync or Black Burst.
On all 8 inputs.
On all 8 inputs.
10
1
2 x USB-C supporting 720p or 1080p at PGM frame rate.
1 x 12G-SDI
1 x HDMI 2.0
RJ12 supports RS-422
Ethernet. Direct connection between panel and chassis, or via network.
Yes
RJ45 for 3rd party talkback systems.
Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included).
4 x RJ45 with internet network switch. Supports 10/100/1000/10G BASE-T.
2 x USB-C supports USB 3.0 for external drive recording, webcam out, software control, software updates and switcher connection.
None
720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60
2160p23.98, 2160p24, 2160p25, 2160p29.97
2160p30, 2160p50, 2160p59.94, 2160p60
SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2081-1, SMPTE 2081-10, SMPTE 2082-1 and SMPTE 2082-10.
4:2:2
10-bit.
Rec 709
Automatically detects between 1.5G-SDI, level A or level B 3G-SDI, 6G-SDI and 12G-SDI.
1
10
20
Tri-Color LED
6 rows 24 character LCD
1
1
10 plus shift 10
5
Set via system LCD menu display
8
12
1
2
2
6
1
1
1
1
4
2
4
1
2
7
1 Stinger, 1 DVE.
8
7
2
Integrated panel with full control of switching and settings.
16
Yes
Red for program and green for preview indication.
Yes
Yes
Supports direct live streaming using Real Time Messaging Protocol (RTMP) over ethernet or a shared internet connection over USB‑C.
Direct recording to optional internal M.2 flash memory or to external media via USB-C expansion ports.
HD programs recorded as a H.264 .mp4 file at the streaming quality setting and at the ATEM video HD standard with AAC audio.
Ultra HD programs recorded as a H.265 HEVC file at the streaming quality setting and at the ATEM video Ultra HD standard with AAC audio.
Supports media formatted ExFAT (Windows/Mac). APFS or HFS+ (Mac).
Learn More1 x multi view via SDI and HDMI configurable to 16, 13, 10, 7 or 4 up views. Includes monitoring of Program, Preview, Inputs, Media Players, DSKs, SuperSource, Clean Feed with optional labels and audio meters.
HD or Ultra HD
1366 x 768
2
Fill and key for each media player.
20
PNG, TGA, BMP, GIF, JPEG and TIFF.
2 x up to 2160p60.
720 frames.
360 frames.
90 frames.
TGA sequence.
WAV, MP3 and AIFF.
< 10 lines when genlocked and in the same format as the switcher.
58 Channel mixer.
Selectable On/Off/Audio-Follow-Video.
Level and Peak metering.
Master gain control.
6 band parametric EQ, Dynamics including Expander, Gate, Compressor and Limiter.
When used with most Blackmagic Design cameras, ATEM can control focus, iris and zoom of compatible lenses and camera settings including gain, white balance, tint, shutter, ND filter, color corrector, tally and record start/stop.
1 x multi view
ATEM Software Control Panel included free for Mac 12.0 Monterey, Mac 13.0 Ventura or later. and Windows 10 or 11.
Using USB or Ethernet connection directly connected to Mac or Windows computers. Includes ATEM Setup Utility.
Mac 14.0 Sonoma,
Mac 15.0 Sequoia or later.
Windows 10 and 11.
1 x Internal 100 - 240 AC 50/60Hz with IEC C14 socket.
1 x 4 pin XLR 12V DC In for external power supply or battery use.
120 W
Desktop or in-desk mount.
0° to 40° C (32° to 104° F)
-20° to 60° C (-4° to 140° F)
0% to 90% non-condensing
ATEM Television Studio 4K8
Welcome wallet with QR code for software download
1 Year Limited Manufacturer’s Warranty.
ATEM Television Studio 4K8
Welcome wallet with QR code for software download
