Blackmagic ATEM 2 M/E Advanced Panel 40

The ATEM 2 M/E Advanced Panel 40 offers unmatched control and flexibility for advanced live production workflows, featuring 40 input buttons per row and eight customizable LCDs.

1-3 werkdagen
  • €7.935,00 (excl. btw)
    €9.601,35 incl. btw
  • €8.625,00
  • - 8%

The ATEM 2 M/E Advanced Panel 40 is a professional-grade hardware panel designed for advanced live production environments. This panel features 40 input buttons per row, providing extensive control over a wide range of sources and functions. Each row is equipped with an independent system control LCD, ensuring unparalleled flexibility and precision. With eight customizable LCDs for labels, users can easily manage complex effects and configurations. The panel includes high-quality broadcast buttons, rotary knobs, and a T-bar fader, offering an intuitive and efficient way to operate all switcher functions simultaneously. Ideal for use with the ATEM Constellation, the panel allows access to all M/Es with an input button for every SDI source. The ATEM 2 M/E Advanced Panel 40 supports the most sophisticated live switching workflows, featuring separate program and preview buses for quick and accurate source selection. This panel enhances the live production experience by making it more streamlined and enjoyable, enabling users to handle intricate productions effortlessly.

Connections

Ethernet

4 x 10/100/1000 BASE-T with loop outputfor additional control panels or computers.

Software Updates

1 x USB-C for firmware updates.

ATEM 2 M/E Advanced Panel 40

Product Specifics

Number of Mix Effects Rows

2

Direct Cross Points

40

Shifted Cross Points

80

Crosspoint Button Type

Tri-Color LED

Crosspoint Label

6 rows 24 character LCD

On-Air indicator

12

Power Status Indicators

None

DSK Transition Selectors

4 x Auto, Cut, Tie/Preview

Preview Transition

2

Transition Rate Displays

Via main menu

LCD Menu Displays

4

Menu Control

4 x 20 buttons

Dedicated Macro Buttons

2 x 40

Transport Control Buttons

8

Destination Bus

2

Source Select Bus

2

Fader Bar

2

3 Axis Joystick

1

Numeric Keypad

1

Software

Software Applications

ATEM Software Control Panel.

Operating Systems

Mac icon

Mac 14.0 Sonoma,
Mac 15.0 Sequoia or later.

Windows Icon

Windows 10 and 11.

Power Requirements

Input Voltage

2 x Internal 100 - 240V AC.

Redundant Power

Yes

Power Usage

160W

Physical Specifications

ATEM 2 M/E Advanced Panel 40

Environmental Specifications

Operating Temperature

0° to 40° C (32° to 104° F)

Storage Temperature

-20° to 60° C (-4° to 140° F)

Relative Humidity

Up to 95%



ATEM 2 M/E Advanced Panel 40

Welcome wallet with QR code for software download
