De HBT-50 levert stroom, videosignaal en camerabediening tot 4 apparaten tot 100 meter afstand. Het voert tegelijkertijd HDMI-, SDI-, RS-422- en IP-besturingssignalen uit.
The HBT-50 supplies power, video signal, and camera control up to 4 devices up to 100 meters distance. It simultaneously outputs HDMI, SDI, RS-422 and IP control signals.
HBT-50 simultaneously transmits SDI (up to 1080p60) and HDMI (up to 1080p60) as well as camera control. With the HBT-50, the system can be integrated camera controller, video switcher, and ISO recorder.
HBT-50 provides outputs HDMI and SDI simultaneously. It is great us on long distance camera video transmitting to switcher, or ISO recorder. These is no need to prepare 4 additional HDBaseT receiver, HBT-50 will get the work done for it.
Remote control of camera functions via RS-422 or DVIP with SDI video transmission (up to 1080p50/60) and HDMI video transmission (up to 1080p50/60) up to 4 cameras simultaneously up to 100m.
HBT-50
HDBaseT x 4 (with PoE and IEEE 802.3at)
HDMI x 4 (up to 1080p50/59.94/60)
SDI x 4 (up to 1080p50/59.94/60)
1080p: 60/59.94/50/30/29.97/25/24/23.98
1080i: 60/59.94/50, 720p: 60/59.94/50
---
---
RJ-45 x1(input)
RJ-45 x 4 (RS-232/RS-422)
AC In
65W per channel
1080p50/59.94/60 up to 100m by CAT.6 cables
---
---
---
440 x 286 x 49mm
4.2 kg
0~40 °C
