Blackmagic Mini Converter Analog to SDI

SDI Video Outputs

2 x SDI Video Outputs.

Analog Video Inputs

NTSC, PAL, S‑Video and Component SD/HD input.

Analog Audio Inputs

2 channels of balanced analog audio.

Digital Audio Inputs

2 channels of balanced AES/EBU audio.

Multi Rate Support

Auto detection of SD or HD.

Updates and Configuration

Via USB 2.0 high speed. (480 Mb/s)

Reclocking

Yes

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60

SDI Compliance

SMPTE 259M, SMPTE 292M, SMPTE 296M, ITU‑R BT.656 and ITU‑R BT.601.

SDI Video Sampling

4:2:2

SDI Audio Sampling

Television standard sample rate of 48 kHz and 24 bit.

SDI Color Precision

4:2:2

SDI Color Space

YUV

SDI Auto Switching

Automatically follows format of analog input.

Analog Color Space

YUV

Analog Color Precision

4:2:2

Software Control

Mac™ and Windows™ software upgrade via USB.

Internal Software Upgrade

Via included updater application.

Power Supply

+12V universal power supply included with international socket adapters for all countries. Cable tie point.

Power Consumption

6.50 Watts

Operational Voltage Range

12 ‑ 31V DC

Mac 10.15 Catalina,
Mac 11.1 Big Sur or later.

Windows 10, 64-bit.

Operating temperature

0° to 40° C (32° to 104° F)

Storage temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing
