SWIT 140Wh Pocket V-mount Battery Pack (Mino-S140)
140Wh pocket-sized V-mount battery with 150W high load, USB-C 65W, D-tap, and drop-proof design. Ideal for RED and compact cine cameras.
140Wh pocket-sized V-mount battery with 150W high load, USB-C 65W, D-tap, and drop-proof design. Ideal for RED and compact cine cameras.
The MINO-S140 is a compact yet powerful 140Wh V-mount battery designed for modern cine and broadcast workflows. Despite its pocket-sized form factor, it delivers a high 150W/12A constant load, making it ideal for power-hungry cameras like RED V-Raptor, KOMODO, and Kinefinity MAVO. It features a wire-free internal structure for enhanced safety and durability, and is drop-tested to withstand falls from up to 1.2 meters. The battery includes a D-tap port for output and charging, a USB-A 5V/2A output, and a USB-C port supporting 48W input and 65W output—perfect for charging laptops and accessories on set. A 4-step LED indicator shows remaining power, and the battery communicates power info to both SONY and RED cameras. With multiple circuit protections and a rugged design, the MINO-S140 is a reliable, high-performance solution for mobile production environments.
Battery plate |
V-mount |
Nominal voltage |
14.4V |
Capacity |
140Wh, 9.7Ah |
Power IN&OUT |
Electrodes: 150W 12A out, 16.8V 3A in |
D-tap: 120W 10A out, 16.8V 3A in |
|
USB-A: 10W, 5V/2A out | |
USB-C: Max 65W out, 5V/9V/12V/15V/20V(Max) 3.25A BC1.2, PD2.0/3.0, QC2.0/3.0, FCP, SCP Max 48W in, 5V/9V/12V/15V/20V(Max) 2.4A |
|
Dimension |
105×79×55.5mm (Fit Red Raptor) |
Charging Temperature | 0-40°C |
Discharging Temperature |
-20°C-50°C (Capacity and Max Load may decrease when operating below 0°) |
Net weight |
Net 713g; With package 0.75kg |
