BlackMagic Design
CONVNVIPM/12G/HDMI02

Blackmagic 2110 IP SDI to HDMI 12G

A precision monitoring bridge that converts 12G‑SDI or SMPTE 2110 IP signals to HDMI with calibrated colour, full audio support and broadcast‑grade reliability.

1-3 werkdagen
  • €391,50 (excl. btw)
    €473,72 incl. btw
  • €435,00
  • - 0%
This rack‑mount monitoring converter is designed for professional broadcast and live production environments that need reliable viewing of SDI or SMPTE ST 2110 IP signals on modern HDMI displays. It bridges traditional 12G‑SDI infrastructures and IP‑based workflows with high precision, making it ideal for control rooms, technical monitoring positions and mobile production units. By combining baseband and IP inputs in a single device, it simplifies signal routing while maintaining full broadcast quality.
The unit accepts both 12G‑SDI and SMPTE ST 2110 IP video, automatically converting incoming signals to HDMI for monitoring. It supports the full range of SD, HD, 2K, Ultra HD and DCI 4K formats up to 2160p60, ensuring compatibility with current and future production standards. A built‑in 3D LUT system allows accurate colour calibration of connected HDMI monitors, which is essential for critical viewing and confidence monitoring in broadcast environments.
Audio handling is equally comprehensive. Up to 16 channels of embedded audio are supported on SDI and IP inputs, while HDMI outputs can carry up to 8 embedded channels. In addition, the converter includes two balanced XLR analog audio outputs with adjustable gain and delay, allowing direct connection to professional audio monitoring systems. A front‑panel speaker and a 6.35 mm headphone output provide convenient local audio monitoring without the need for external equipment.
Network connectivity is provided via a single 10 Gb Ethernet port that supports SMPTE ST 2110 video, audio and ancillary data. This connection is also used for configuration, firmware updates and system management. A USB‑C port adds further flexibility by providing a webcam output up to 1080p60, enabling easy integration with computers for streaming, conferencing or capture applications. The front panel features an LCD display showing video, audio meters and menu settings, allowing engineers to quickly confirm signal status and adjust configuration directly at the unit.
Designed for reliability and precision, this monitoring solution supports full ancillary data pass‑through, including timecode and closed captions, and complies with a wide range of SMPTE standards. Its compact rack‑mount design makes it easy to integrate into existing installations while supporting the transition to IP‑based production workflows.

Connections

SDI Inputs

1

SDI Loop Outputs

1

SDI Rates

SD, 1.5G, 3G, 6G and 12G

HDMI 2.0 Video Outputs

1

SMPTE 2110 Input / Output

1 x 10G Ethernet

SMPTE ST 2110 IP Audio Inputs / Outputs

16 channels embedded input and output audio on ST‑2110 IP video via 10G Ethernet.

SDI Audio Inputs

16 channels embedded audio.

SDI Audio Outputs

16 channels embedded audio.

HDMI Audio Inputs

8 channels embedded audio.

HDMI Audio Outputs

8 channels embedded audio.

Analog Audio Outputs

2 channels of professional balanced analog audio with 3‑pin XLR connectors.

1 x 6.35 mm headphone jack.

Webcam Outputs

1 x USB‑C up to 1080p60

Ethernet

Ethernet supports 10/100/1000/10G BASE‑T for SMPTE 2110 IP video in and out, configuration and software updates.

Computer Interface

USB‑C for webcam out, updates and configuration

Blackmagic 2110 IP SDI to HDMI 12G

Video Standards

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60,
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30

2K Video Standards

2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI, 2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI, 2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI,
2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI, 2KPsF29.97 DCI, 2KPsF30 DCI

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60

4K Video Standards

4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI, 4Kp60 DCI

SMPTE Compliance

SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M, SMPTE 424M, SMPTE 425M level A and B, SMPTE 2036‑1, SMPTE 2048‑1, SMPTE 2081‑10, SMPTE 2081‑11, SMPTE 2081‑12, SMPTE 2082‑10, SMPTE 2082‑11, SMPTE 2082‑12 and SMPTE ST2108‑1

SDI Metadata Support

RP 188/SMPTE 12M‑2 and closed captioning.

Audio Sampling

Television standard sample rate of 48 kHz and 24 bit.

Color Precision

8, 10 RGB 4:4:4 in all modes up to 1080p30 and 8, 10‑bit YUV 4:2:2 in all modes.

Color Space

Rec. 601, Rec. 709, Rec. 2020

HDMI HD Video Standards

720p50, 720p59.94, 720p60
1080i50, 1080i59.94, 1080i60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p47.95, 1080p48, 1080p50, 1080p59.94, 1080p60

HDMI Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p47.95, 2160p48, 2160p50, 2160p59.94, 2160p60

HDMI 4K Video Standards

4Kp23.98 DCI, 4Kp24 DCI, 4Kp25 DCI, 4Kp29.97 DCI, 4Kp30 DCI, 4Kp47.95 DCI, 4Kp48 DCI, 4Kp50 DCI, 4Kp59.94 DCI and 4Kp60 DCI

HDMI Color Precision

4:2:2

HDMI Color Space

YUV

Audio

Local Audio Monitoring

Front panel audio monitor speaker with speaker control button, plus 6.35 mm headphone socket.

IP Video Compliance

SMPTE 2110-20 (Uncompressed Video)

IGMP v2

SMPTE 2110-21 (Traffic Shaping)

Sender: Narrow

Receiver: Narrow, Wide Synchronous, Asynchronous

SMPTE 2110-30 (PCM)

Audio Conformance level: Level C

SMPTE 2110-40 (Ancillary Data)

Full access to entire SMPTE ancillary data stream. Includes RP 188/SMPTE 12M‑2, closed captioning and HDR static metadata.

Codec

Blackmagic IP10 codec used when converting 2160p59.94 and 2160p60 to 10G 2110 IP video.

Precision Time Protocol

IEEE 1588-2008 (PTP v2)

ST 2059-1

ST 2059-2

NMOS IS-04 Discovery and Registration

v1.3.2

Peer-to-peer via mDNS/DNS‑SD

NMOS IS-05 Connection Management

v1.1.2

NMOS BCP-002-01

Natural Grouping

NMOS BCP-004-01

Receiver capabilities

Control

Built in Control Panel

Built in control panel including 4 buttons, spin knob control and 2.2 inch color display.

External Control

RJ-45 10Gb/s Ethernet and USB‑C.

REST API over Ethernet for external control via HTTP when used with REST client applications.

Displays

Built in 2.2 inch LCD for monitoring video, audio and status plus menu settings.

Operating Systems

Mac icon

Mac 13.0 Ventura,
Mac 14.0 Sonoma or later.

Windows Icon

Windows 10 and 11.

Power Requirements

Power Supply

1 x Internal 100 - 240V AC 50/60Hz.

Power Supply

1 x IEC C14 socket for AC power.

1 x Locking 5.5mm barrel +12V DC input for external power supply or battery use.

Power Usage

TBC

Physical Installation

One third rack unit width, 1 rack unit height.

Physical Specifications

Blackmagic 2110 IP SDI to HDMI 12G

Environmental Specifications

Operating Temperature

0° C to 40° C (32° - 104°F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non‑condensing

What's Included

Blackmagic 2110 IP SDI to HDMI 12G

Welcome wallet with QR code for software download

Warranty

1 Year Limited Manufacturer’s Warranty.

  • Blackmagic 2110 IP SDI to HDMI 12G
  • Welcome wallet with QR code for software download
