TVLogic LVM-095W-N 9"FHD monitor

9" Full HD 3G-SDI monitor with advanced analysis tools—ideal for compact broadcast and field setups requiring precision and portability.

1-3 werkdagen
  • €2.899,00 (excl. btw)
    €3.507,79 incl. btw
  • - 0%

The TVLogic LVM-095W-N is a compact yet powerful 9-inch Full HD monitor designed for professional broadcast, studio, and field applications where space and precision matter. With a native resolution of 1920x1080 and 3G-SDI support, it delivers sharp, color-accurate images ideal for critical monitoring tasks. Its lightweight design and robust build make it perfect for rack-mount or portable use, while advanced features such as waveform, vectorscope, focus assist, and audio level meters ensure comprehensive signal analysis. The LVM-095W-N also supports multiple input formats and includes user-configurable function keys, making it a versatile tool for any production environment that demands reliability and clarity in a compact form factor.

Size 9"

Resolution 1920 x 1080 (16:9)

Pixel Pitch 0.1035mm

Color Depth 16.7M Colors

Viewing Angle (Typ.) 176°(H) / 176°(V)

Luminance (Max.) 400nits

Contrast Ratio 750:1

Display Area 198(H) x 111(V) mm

Audio In Embedded Audio / Analog stereo

(Phone Jack)

Audio Out Analog stereo (Phone Jack) /

Internal Speaker (Mixed Mono)

Power DC 12V / 24V

Power Consumption

(Approx.)

DC 24 Watts (Max. 2A)

Operating Temperature 0°C to 45°C (32°F to 113°F )

Storage Temperature -20°C to 60°C (-4°F to 140°F )



Input

2 x BNC SDI A/B Channel Input

1 x HDMI HDMI Input



Output

1 x BNC SDI A/B Selectable Output



Input Signal

Analog CVBS (SDI B Channel)

3G-SDI 2.970Gb/s

HD-SDI 1.485Gb/s

SD-SDI 270Mb/s

HDMI

(PC & HDMI mode) 1080p(60)/1080i(60)/720p(60)/480p(60)/576p(50)

AC Power Cable DC Power Adaptor Table Stand
