  • Sony PXW-FX9 XDCAM 6K Full-Frame Camera (Body Only)
  • Sony PXW-FX9 XDCAM 6K Full-Frame Camera (Body Only)
  • Sony PXW-FX9 XDCAM 6K Full-Frame Camera (Body Only)
Sony
PXW-FX9V

Sony PXW-FX9 XDCAM 6K Full-Frame Camera (Body Only)

Levertijd opvraagbaar
  • €11.000,00 (excl. btw)
    €13.310,00 incl. btw
  • - 0%

The PXW-FX9 input and output features include 12G-SDI and HDMI outputs for 4K, a 3G-SDI output for HD, and genlock and timecode when using a multicamera setup. The Fast Hybrid AF autofocus system allows for accurate focus and even allows facial detection to automatically detect human form with 561 points of detection. Advanced image stabilization is achieved using the PXW-FX9's internal gyroscope for shots so smooth it'll look like you used a gimbal. Its 4-channel audio recording allows you to use external microphones and record ambient sound with the internal mics simultaneously.

The camera features a 15-stop dynamic range and records 10-bit 4:2:2 to dual XQD media card slots that support simultaneous and relay recording, as well as multiple backup recording modes that utilize proxy files. The camera can record DCI (4096 x 2160), UHD (3840 x 2160), and HD (1920 x 1080) internally at a selectable frame rate from 1 fps up to 60 fps in XAVC-I, XAVC-Long, and MPEG HD formats. And with a future firmware update, it will be able to record HD at up to 180 fps and output 16-bit raw 4K/2K footage up to 120 fps. In addition to its wide dynamic range, its enhanced color and light features include a dual base ISO of 800/4000, which is helpful when in low-light situations or using a slower lens. Its 7-stop electronic variable HD filter can perform in auto or manual mode, smoothly adjusting from 1/4 to 1/128 density. The camera's default S-Cinetone color look offers the same soft, vivid tone as with Sony's VENICE camera.

The FX9 includes an integrated Multi-Interface (MI) shoe and comes with a BP-U35 battery, BC-U1A battery charger, AC adapter with two power cords, body cap, viewfinder, eyepiece, remote control, and USB cable. The PXW-FX9 is also compatible with the separately available XDCA-FX9 extension unit which provides ENG shoulder-style support, networking features, and a slot for an optional wireless audio receiver.

The PXW-FX9's oversampled full-frame 6K sensor provides recording in DCI 4K, UHD, and HD resolutions. Powerful image processing with debayering and down-sampling ensures image quality beyond the limits of conventional Super 35mm sensors. The back-illuminated CMOS image sensor also uses Sony's Exmor R technology for improved sensitivity and noise reduction. Compared to a 4K Super 35mm sensor, the FX9's 6K sensor has over twice the surface area while providing a wider angle of view and shallower depth of field.

Image Sensor

Image Sensor Size

35.7 x 18.8 mm (Full-Frame)

Sensor Type

CMOS

Sensor Resolution

Effective: 3840 x 2160

ISO

800 to 4000 (Native)

Gain

-3 to 18 dB

Advertised Dynamic Range

15 Stops

Signal-to-Noise Ratio

57 dB



Camera

Lens Mount

Sony E-Mount

Shutter Speed

1/1 to 1/8000 sec

Built-In ND Filter

4 to 128 Stop Electronic ND Filter

Built-In Microphone Type

Mono

Recording Media

2 x XQD Card Slots
1 x SDXC/Memory Stick PRO Duo Hybrid Card Slot



Internal Recording

Recording Modes

XAVC-I 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (240 to 600 Mb/s)
1920 x 1080p at 23.98/25/29.97/50/59.94/100/120 fps (89 to 222 Mb/s)
1920 x 1080i at 50/59.94 fps (112 Mb/s)
XAVC-L 4:2:2 10-Bit:
3840 x 2160p at 23.98/25/29.97/50/59.94 fps (100 to 150 Mb/s)
1920 x 1080p at 25/29.97/50/59.94/100/120 fps (25 to 50 Mb/s)
1920 x 1080i at 50/59.94 fps (50 Mb/s)
MPEG HD422 4:2:2 10-Bit:
1920 x 1080p at 23.98/25/29.97 fps (50 Mb/s)
1920 x 1080i at 25/50/59.94 fps (50 Mb/s)
XAVC Proxy 4:2:0 10-Bit:
1920 x 1080p (9 Mb/s)
1280 x 720p (6 to 9 Mb/s)
640 x 360p (3 Mb/s)

Gamma Curve

Sony S-Log 3

Audio Recording

XAVC: 4-Channel 24-Bit 48 kHz LPCM Audio
Proxy: 2-Channel AAC Audio



Interfaces

Video Connectors

1 x BNC (12G-SDI) Output
1 x BNC (3G-SDI) Output
1 x HDMI (HDMI 2.0) Output

Audio Connectors

2 x 3-Pin XLR Mic/Line Level (+48 V Phantom Power) Input
1 x 1/8" / 3.5 mm Stereo Headphone Output

Other I/O

1 x BNC Genlock Data Input
1 x BNC Timecode Data Input/Output
1 x 2.5 mm LANC Control
1 x USB Micro-B USB 3.1 Gen 1 Data

Wireless Interfaces

2.4 GHz, 5 GHz Wi-Fi



EVF

EVF

Included

EVF Display Type

LCD

Screen Size

3.5"

EVF Resolution

2,760,000 Dots



Power

Battery Type

Sony BP-U Series

Power Connectors

1 x Barrel (19.5 VDC) Input

Power Consumption

35.2 W





Environmental

Operating Temperature

32 to 104°F / 0 to 40°C

Storage Temperature

-4 to 140°F / -20 to 60°C



General

Accessory Mount

1 x Multi-Interface Shoe
1 x 1/4"-20 Female

Dimensions

5.75 x 5.61 x 9.02" / 146 x 142.5 x 229 mm (Without Protrusions)

Weight

4.4 lb / 2 kg
